تفاصيل المنتج:
|
| Part Number: | N9K-C93180LC-EX | Ports: | 24x 40/50G, 6x 40/100G |
|---|---|---|---|
| Throughput: | 3.6Tbps | Latency: | Sub-microsecond |
| Buffer: | 25MB | Power Consumption: | 290W |
| Total Ports: | 30 |
The Cisco Nexus 9300, N9K-C93180LC-EX, is a high-performance data center switch ideal for large-scale enterprise networks. Providing 24 ports of 40/50G QSFP+ and 6 ports of 40G/100G QSFP28, it delivers exceptional scalability, enhanced speed, and robust connectivity. Targeted at data-intensive applications, it's perfect for cloud environments, enterprise core, and distribution networks.
| Model | Cisco N9K-C93180LC-EX | Arista 7050X3 | Juniper QFX5200 | Huawei CE8860-4C-EI | Extreme VDX 6940-36Q | D ell S5232F-ON | HPE 5945 |
|---|---|---|---|---|---|---|---|
| Ports | 24x 40/50G, 6x 40/100G | 32x 40/100G | 48x 10G, 6x 40/100G | 32x 100G | 36x 40G | 32x 100G | 48x 25G, 6x 100G |
| Throughput | 3.6Tbps | 6.4Tbps | 2.56Tbps | 6.4Tbps | 2.88Tbps | 6.4Tbps | 3.6Tbps |
| Latency | Sub-microsecond | 450ns | 700ns | 300ns | 700ns | 450ns | 850ns |
| Buffer | 25MB | 16MB | 22MB | 14MB | 32MB | 16MB | 15MB |
| Power Consumption | 290W | 700W | 500W | 295W | 655W | 400W | 450W |
| Dimension (H x W x D) | 8.8 x 44.5 x 51.5 cm | 4.4 x 43.8 x 46 cm | 4.4 x 43.7 x 44 cm | 4.36 x 44 x 50 cm | 4.3 x 44 x 44 cm | 4.4 x 43.4 x 53.8 cm | 4.4 x 44 x 55 cm |
| Accessory Model | Description |
|---|---|
| SFP-10G-SR-S | Cisco 10GBASE-SR SFP Module |
| C2G 40G-40G-1M | 1m 40G QSFP+ to QSFP+ Cable |
| CAB-Q-Q-5M | 5m Cisco QSFP+ Cable |
Discover unbeatable prices and fast shipping for the Cisco N9K-C93180LC-EX. Access the detailed N9K-C93180LC-EX datasheet and ensure you're getting the best deal with our reliable delivery service. Need assistance? Our free live chat support is here to help. For more information about the product and pricing, contact us via live chat or email us at sales@router-switch.com.
N9K-C93180LC-EX Specifications |
|
| Brand | Cisco |
| Model | N9K-C93180LC-EX |
| Product Type | Network Switch |
| Port Types | 40/50G QSFP+, 40G/100G QSFP28 |
| Total Ports | 30 |
| 40/50G QSFP+ Ports | 24 |
| 40G/100G QSFP28 Ports | 6 |
| Switching Capacity | 7.2 Tbps |
| Forwarding Rate | 2.4 Bpps |
| Supported Protocols | L2/L3, VXLAN, OTV, and more |
| Management | CLI, SNMP, Syslog |
| Operating System | NX-OS |
| L2 Multicast | Yes |
| L3 Multicast | Yes |
| Dimensions (HxWxD) | 1.72 x 17.3 x 22.5 inches |
| Max Power Consumption | 500W |
| Redundant Power | Yes |
| Cooling | Hot-swappable fan trays |
| Environmental Operating Temperature | 32°F to 104°F (0°C to 40°C) |
| Warranty | Limited lifetime |
