تفاصيل المنتج:
|
| اسم المنتج: | محولات شبكة هواوي | رقم الجزء: | S5736-S48U4XC |
|---|---|---|---|
| قسط: | تي تي | شحنة: | دي إتش إل |
| حالة: | جديد | مهلة: | 2-3 أيام |
| ضمان: | 1 سنة | الكلمات الرئيسية: | S5736-S48U4XC |
| Item | Value |
|---|---|
| Wi‑Fi Standard | Wi‑Fi 7 (802.11be) |
| Bands | 2.4GHz (2×2), 5GHz (2×2), 6GHz (4×4) |
| Total Spatial Streams | 8 |
| Max Rate | 13.66 Gbps |
| Max Concurrent Users | 1800 |
| Ports | 1×5GE, 1×GE, 1×USB, BLE 5.2 |
| Power | PoE (802.3at/af) / DC 12V |
| Dimensions | Φ220 × 45 mm |
| Parameter | Details |
|---|---|
| General | |
| Product Model | AirEngine 6776‑57T |
| Product Type | Indoor Access Point (AP) |
| Radio | |
| Wi‑Fi Standard | IEEE 802.11a/b/g/n/ac/ax/be (Wi‑Fi 7) |
| Frequency Bands | 2.4GHz, 5GHz, 6GHz |
| MIMO | 2.4GHz: 2×2; 5GHz: 2×2; 6GHz: 4×4 |
| Spatial Streams | 8 total |
| Max PHY Rate | 13.66 Gbps (2.4GHz: 689Mbps; 5GHz: 1.44Gbps; 6GHz: 11.53Gbps) |
| Modulation | 4096‑QAM, 1024‑QAM, 256‑QAM, etc. |
| Bandwidth | Up to 320MHz (6GHz) |
| Antenna | Built‑in smart antennas; Gain: 2.4GHz:4dBi, 5GHz:5dBi, 6GHz:5dBi |
| Max Tx Power | 2.4GHz:23dBm; 5GHz:23dBm; 6GHz:26dBm |
| Interfaces | |
| Ethernet | 1×5GE (PoE in), 1×GE electrical port |
| USB | 1×USB (for IoT expansion) |
| Bluetooth | BLE 5.2 (for O&M) |
| Performance | |
| Max Concurrent Users | 1800 (600 per radio) |
| Max SSIDs per Radio | 16 |
| Power | |
| Input | DC 12V ±10%; PoE: 802.3at/af |
| Max Power Consumption | 21.1W (excl. USB) |
| Physical | |
| Dimensions | Φ220 mm × 45 mm |
| Weight | 0.75 kg |
| Environment | |
| Operating Temp | –10°C to +50°C |
| Storage Temp | –40°C to +70°C |
| Humidity | 5%–95% (non‑condensing) |
| Altitude | –60m to +5000m |
